Optical Magnification
|
4 X
|
|
Field of View
|
7°
|
|
Sensor (microbolometer)
|
324 x 256 px
|
|
Frame Rate
|
9 Hz
|
|
Spectral Response
|
7 - 14 ?m
|
|
Display
|
Color OLED matrix, SVGA< 800x600, Color background + color reticules/800 x 600
|
|
Type
|
Uncooled
|
|
Material
|
Vanadium oxide (VOx)
|
|
Video Output
|
Yes
|
|
Thermal Sensitivity
|
< 50 mK
|
|
Lens System
|
50 mm
|
|
Eye Relief
|
27 mm
|
|
E-Zoom
|
8x, 16x
|
|
Diopter Adjustment
|
-1.5
|
|
Distance of the human detection
|
1300 m
|
|
Distance of the human recognition
|
500 m
|
|
Distance of the human identification
|
320 m
|
|
Distance of the vehicle detection
|
2800 m
|
|
Distance of the vehicle recognition
|
1100 m
|
|
Distance of the vehicle identification
|
700 m
|
|
Reticle
|
No
|
|
Reticle Color
|
No
|
|
Polarity Control
|
White hot / Black hot / Multiple Color Modes
|
|
Start up Time
|
< 4 sec
|
|
Environmental Rating
|
Water resistant
|
|
Battery Type
|
1 x 3V (CR123A)
|
|
Battery Life
|
2+ hours
|
|
Weapon mountable
|
No
|
|
Low Battery Indicator
|
Yes
|
|
Iconology
|
Quick access, Icon driven feature controls
|
|
Dimensions
|
6.5" x 2.4" x 3.3"/165 mm x 61 mm x 83 mm
|
|
Weight
|
1.4 lbs
|
|
Weight kg
|
0.64 kg
|
|
Brightness Adjustment
|
Manual
|
|
Sharpness Adjustment
|
Automatic
|
